LS 150/38 CB

We are sorry, but this product is no longer produced.
Chipper with petrol engine on braked chassis LS 150/38 CB
Chipper with petrol engine on braked chassis

The chipper LS 150/38 CB is designed for disposal of wood waste, twigs, bark, branch-wood and other above-ground biomass. It can dispose all these materials with diameters up to 150 mm. The chipper is also equipped with two loading rolls hydraulically controlled and linked to an automatic system as overload protection of its combustion engine. Furthermore, standard equipment comprises also hour counter (daily/total), turnable and tiltable discharge duct and air-cooled 35 HP Kohler petrol engine.

This chipper assembly, completed also with an overrun brake, can be coupled to towing vehicles (even passenger cars). For such a road train up to 3,5 t the driver should keep a driving licence at least of the group B.

Code: LS-4007

5 ÷ 10 m3/h
750
Max. 150 mm

Technical specification

Technical specification
LS 150/38CB
Length
3470 mm
Width
1590 mm
Height
2380 mm (1690 mm – transport)
Weight
750 kg
Fuel consumption
7,8 l/h
Recommended branch-wood maximum diameter
150 mm
CUTTING HEAD
Diameter
560 mm
Number of blades
2
FEEDING DEVICE
Feeding hole size (B×H)
290 × 220 mm
Number of rolls
2
HOPPER
Feeding profile (B×H)
910 × 810 mm
ENGINE
KOHLER CH 980S
Power output
26,1 kW (35 HP)
Fuel
Natural 95
Fuel tank capacity
16 l
Work safety elements
Machine-hour meter, master power switch, safety grip, overrun brake
