LS 160 T (540 rpm)

Powerful chipper for coupling to tractors (540 rpm) LS 160 T (540 rpm)
Powerful chipper for coupling to tractors (540 rpm)

The chipper LS 160 T is a compact machine intended for disposal of wood waste with diameters up to 160 mm. It should be coupled to a tractor with a corresponding three-point linkage (cat. 1 or 2). For machine drive you need also PTO shaft assembly for 540 rpm. The tractor-mounted chipper is equipped with two loading rolls hydraulically controlled and linked to an automatic system as overload protection of the PTO shaft. Furthermore, standard equipment comprises independent hydraulic system, hour counter (daily/total) and turnable and tiltable discharge duct.

Code: LC-13001

12 ÷ 16 m3/h
40 ÷ 80 HP
Max. 160 mm

Technical specification

TECHNICAL SPECIFICATION
LS 160 T (540)
Length
2265 mm ; 1905 mm (transport)
Width
1280 mm
Height
2350 mm ; 1760 mm (transport)
Weight
568 kg
Load
ca. 12 ÷ 16 m3/hr
Recommended branch max. diameter
160 mm
CUTTING HEAD
Diameter
600 mm
Number of blades
2
Wood chips size
5 ÷ 15 mm
Turning on
freewheel clutch
FEEDING DEVICE
Feeding hole size (B×H)
240 x 170 mm
Number of rolls
2
HOPPER
Directional rotation
--
Feeding profile (B×H)
1040 x 800 mm
TRACTOR HITCH
3-point linkage
Category 1, 2
Power PTO
30 ÷ 60 kW (40 ÷ 80 HP)
PTO
540 rpm
Electrical system
12V
WORK SAFETY ELEMENTS
Machine-hour meter, charging indicator lamp, master power switch, safety grip
ACCESSORIES
Electronic regulation - NOSTRESS
ACCESSORIES options (NOT INCLUDED)
Cardan shaft L=1000 mm (Kardan 4542)
